The U300 Five-Axis Gantry Machining Center is engineered for high-precision, high-efficiency machining of large, complex components. Its rigid bridge-type structure and powerful spindle ensure exceptional stability during heavy-duty cutting operations. Equipped with a reliable five-axis linkage system (typically a dual pendulum rotary table or tilting head), it enables complete machining of intricate contours and surfaces in a single setup. Ideal for industries like aerospace, automotive, mold, and energy, the U300 significantly reduces production time, minimizes errors, and boosts overall productivity.
-
U300
-
LEYO
库存： 0
Inquire
Add to Basket
Product Description
U300 five-axis gantry machining center
Welcome to the future of large-scale precision machining. Our U300 five-axis gantry machining center represents the pinnacle of engineering excellence, designed for manufacturers who refuse to compromise on quality, complexity, and efficiency. This machine is the ultimate solution for producing large, complex parts with unparalleled precision in a single setup.
core technology
Unparalleled rigidity and stability: The robust integrated gantry (bridge) structure, combined with high-quality cast iron and optimized ribbed plate design, provides excellent torsional rigidity and shock absorption. This fundamental stability is crucial for achieving micron-level precision during intense heavy-duty milling processes, even on hard materials such as titanium alloys and quenched steel.
High-performance five-axis linkage: The U300 integrates a precise five-axis system, typically equipped with a high-torque dual-axis rotary table. This allows all five axes to move simultaneously, enabling you to approach the workpiece from any angle. This eliminates the need for multiple setups, reduces cumulative errors, and significantly shortens the production cycle for complex geometries such as impellers, turbine blades, and large molds.
Robust spindle drive: The U300 is equipped with gear transmission or a built-in electric spindle, featuring a wide torque range and high power, enabling it to maintain a constant cutting speed even under heavy loads. Optional spindle cooling and HSK/ABT tool interfaces ensure high-speed precision and extended tool life.
Advanced CNC system: The standard configuration includes a CNC system with strong data processing capabilities, smooth motion control, and a user-friendly programming interface. It supports advanced features such as 3D tool compensation, collision avoidance, and lean manufacturing integration.
Technical specifications (abstract):
X/Y/Z-axis travel: 800/550/550
Speed: 12000/15000/20000
Repositioning accuracy: ≤0.003 millimeters
CNC system: Huazhong/Syntec/Fanuc
Wide range of applications:
In industries where precision and complexity are highly demanded, this machine is indispensable:
Aerospace: structural components, engine casings, landing gear components, spars.
Automobile: large molds, prototypes, body-in-white fixtures, engine blocks.
Energy: turbine blades, wind turbine gearboxes, generator housings.
Molds and Die Casting: Manufacturing large plastic injection molds, die-casting molds, and forging molds.
General heavy machinery: precision machining of large bases, frames, and gears.
Why choose our U300?
We are not just sellers, but also professional manufacturers. By cooperating with us, you will gain:
Factory direct sales price: Eliminate middlemen's markups and enjoy great value discounts.
Customization: We can tailor the itinerary, configuration, and options according to your specific needs.
Comprehensive support: From pre-sales technical consultation to installation, training, and lifelong after-sales service, we will accompany you every step of the way.
Quality assurance: Each machine undergoes rigorous testing and a complete production process before being shipped.
Are you ready to change your production method?
Click "Contact Supplier" or "Request a Quote" now to discuss your technical needs with us and secure a competitive price. Allow us to provide you with detailed solutions and a factory tour experience.
