The Leyo FC500 is a robust gantry CNC machining center engineered for manufacturers who machine large, heavy, and geometrically complex components. Its fixed-table, moving-gantry double-column structure provides the ultimate combination of rigidity, thermal symmetry, and vibration dampening—making it the definitive platform for large format CNC machining of oversized workpieces that exceed the capacity of conventional vertical machining centers.

Built on a heavily ribbed, stress-relieved cast iron frame with precision-ground linear guideways, the FC500 delivers uncompromising geometric accuracy across its entire work envelope. As a true heavy duty gantry CNC mill, it handles aggressive roughing passes and delicate finishing operations on the same setup—eliminating the part transfers and setup accumulations that erode profitability in multi-machine workflows. For manufacturers in aerospace, heavy engineering, and large mold making, the FC500 is not just a machine tool; it is the strategic asset that unlocks contracts on oversized components.

The FC500 gantry type CNC milling machine delivers heavy-duty machining capability across a large work envelope. Key specifications include: XYZ travels, table size & load capacity, spindle power/speed/taper, distance between columns, rapid traverse rates, positioning accuracy, machine dimensions, weight, and foundation requirements.

Technical Specifications Tip：The information provided above is for reference only. Specific technical parameters can be customized according to customer needs, and the actual specifications shall prevail.

Industry and application

Aerospace: A proven gantry CNC system, specifically designed for the aerospace industry, used for machining aluminum and titanium structural ribs, spars, bulkheads, and landing gear components.

Heavy-duty engineering: As a CNC machine tool specifically designed for heavy-duty engineering, the FC500 can easily process gearbox housings, turbine casings, crane components, and mining equipment parts.

Large mold manufacturing: Ideal CNC machine for large mold bases - used for injection molds of car bumpers, instrument panels, and large die-casting molds.

Energy and marine: Processing of wind turbine hubs, propeller molds, and pressure vessel components.

FAQ

What are the advantages of a gantry structure over a C-frame VMC?
A gantry structure like the FC500 provides symmetrical thermal growth and superior vibration dampening, making it a definitive high rigidity gantry machining center for large, heavy workpieces where tool point deviation must be minimized.

What is the maximum workpiece size the FC500 can accommodate?
The FC500 is purpose-built for large format CNC machining—contact our engineering team with your specific part dimensions for a detailed feasibility assessment.
